Specialisted Belting Supplies for Bulk Material Handling |
| Advantage: |
|
Strong tensile strength, long-life, little elongation, easy to trough, anti-bent, suitable for long distance, heavy load and high-speed conveying materials. | |
| Application: |
|
Conveying materials in coal, mine, harbor, metallurgy, power station, chemical etc. field. | |
| Type: |
(1) Conventional, Fire-resistant, Cold-resistant, Abrasion-resistant, Heat-resistant, Acid/alkali-resistant etc.(Referring rubber cover) |
|
(2) General structure, Cross rigid structure, Anti-tearing iron ring structure.
|
|
Type |
Standard and Main Technical |
|
Conventional |
|
|
|
|
Conventional Flame Retardant |
|
|
|
HG2297-92 |
|
|
Shore Abrasion ¡Ü 90mm 3 |
Acid,alkali,oil resistant |
HG4-846 |
|
|
Fragility Temperature -40 ¡æ |
| Technical Data for Steel Cord Belt |
|
|
St
600 |
St
800 |
St
1000 |
St
1250 |
St
1600 |
St
2000 |
St
2500 |
St
3150 |
St
3500 |
St
4000 |
St
4500 |
St
5000 |
St
5400 |
|
Elongation
Tensile Strength(N/mm) |
600 |
800 |
1000 |
1250 |
1600 |
2000 |
2500 |
3150 |
3500 |
4000 |
4500 |
5000 |
5400 |
Max.Diameter
of Cord( mm) |
3.0 |
3.5 |
4.0 |
4.5 |
5.0 |
6.0 |
7.2 |
8.1 |
8.6 |
8.9 |
9.7 |
10.9 |
11.3 |
|
Space
Between
(mm) |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
|
Top Cover Thickness
(mm) |
5 |
5 |
6 |
6 |
8 |
8 |
8 |
8 |
8 |
8 |
8 |
8.5 |
9 |
|
Bottom Cover
Thicknees
(mm) |
5 |
5 |
6 |
6 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8.5 |
9 |
| Width(mm) |
Cord Number |
St
630 |
St
800 |
St
1000 |
St
1250 |
St
1600 |
St
2000 |
St
2500 |
St
3150 |
St
3500 |
St
4000 |
St
4500 |
St
5000 |
St
5400 |
| 800 |
75 |
75 |
63 |
63 |
63 |
63 |
50 |
50 |
50 |
|
|
|
|
| 1000 |
95 |
95 |
79 |
79 |
79 |
79 |
64 |
64 |
64 |
64 |
59 |
55 |
55 |
| 1200 |
113 |
113 |
94 |
94 |
94 |
94 |
76 |
76 |
77 |
77 |
71 |
66 |
66 |
| 1400 |
133 |
133 |
111 |
111 |
111 |
111 |
89 |
89 |
90 |
90 |
84 |
78 |
78 |
| 1600 |
151 |
151 |
126 |
126 |
126 |
126 |
101 |
101 |
104 |
104 |
96 |
90 |
90 |
| 1800 |
|
171 |
143 |
143 |
143 |
143 |
114 |
114 |
117 |
117 |
109 |
102 |
102 |
| 2000 |
|
|
|
|
|
176 |
141 |
141 |
144 |
144 |
134 |
125 |
125 |
| 2200 |
|
|
|
|
|
193 |
155 |
155 |
157 |
157 |
146 |
137 |
137 |
| 2400 |
|
|
|
|
|
209 |
168 |
168 |
170 |
170 |
159 |
149 |
149 |
| 2600 |
|
|
|
|
|
|
|
|
194 |
194 |
171 |
161 |
161 |
| 2800 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Level Code Name |
Tensile Strength
MPa ¡Ý |
Elongation At Break
% ¡Ý |
Abrasion mm 3 ¡Ü |
|
D |
18 |
400 |
90 |
|
H |
25 |
450 |
120 |
|
L |
20 |
400 |
150 |
|
P |
14 |
350 |
200 |
|
NOTE£º
D ¡ª force abrasion operation condition £»
H ¡ª force wear and tear condition £»
L ¡ª conventional operation condition £»
P ¡ª alkali,oi, cold resistant, Conventional Flame Retardant belt |
|
|
|
